Freon Cabinet Type Unit Coolers

Freon Cabinet Type Unit Coolers - Image 3

Freon Cabinet Type Unit Coolers

Features & Applications

FEWR series evaporators are ceiling-mounted, single-discharge blow-through units, distinguished by their high efficiency and compact design. They are designed to operate with commonly used refrigerants such as R404A, R507, R134a, and equivalents.

Coil Features

Straight tube arrangement reducing defrost time and defrost energy consumption
Fin spacing: 4 / 7 mm
Internally grooved copper tubes with aluminum fins, optimized for evaporator applications
Copper inlet and outlet connections
Refrigerant distributor for uniform flow distribution
Optimized refrigerant circuiting
Test pressure: 34 bar (PED 2014/68/EU compliant)
Maximum operating pressure: 22 bar

Casing

Casing manufactured from AlMg3 aluminum alloy
Electrostatic powder-coated finish (RAL 9016), providing a smooth, durable, and corrosion-resistant surface
Hinged side panels and drain pan for easy access and maintenance

Drain Pan

Hinged drain pan in all models

Accessories

Electric defrost heater
Wall mounting brackets
Drain line heater

Options & Versions

Air defrost
Hot gas defrost (coil and drain pan)
Epoxy-coated fins
Coated coil options
Stainless steel casing (AISI 304 / AISI 316)
EC fans
Stainless steel tubes (AISI 304 / AISI 316)
Expansion valve installation
Insulated drain pan
Angled fan shroud
Blow-through fan configuration
High-capacity fans
